Description
Functions
GPS Positioning (Factory Option)
The built-in GPS module supports GIS applications.
Pseudo Trunk
This virtual trunking feature allocates a free timeslot for urgent communications. This effectively enhances frequency efficiency and allows you to communicate in a timely manner in emergency situations.
IP67 Compliance
IP67 rated withstanding up to 1m submersion for 30 minutes or more.
Man Down (Factory Option)
When a user falls down, the radio can automatically alert others.
Radio Priority-Based Interruption
Enable an administration or manager radio to interrupt calls for emergency or urgent communication.
Technical Specifications
General
- Frequency Range
- VHF1: 136-174MHz
UHF1: 400-470MHz, 400-527MHz - Channel Capacity
- 1024
- Zone Capacity
- 64 , each with a maximum of 256 channels
- Battery Life (5-5-90 Duty Cycle)
- Digital:
21 Hours @2000mAh
Analog:
14.5 Hours @2000mAh - Dimensions
- 122 x 54 x 33 mm (2000mAh)
- Weight
- 344g (2000mAh)
- Channel Spacing
- 25/20/12.5kHz
- Frequency Stability
- ±0.5 ppm
- Antenna Impedance
- 50?
Environmental Specifications
- Dust & Water Intrusion
- IP67 Standard
- Operating Temperature
- -30? ~ +55?
- Storage Temperature
- -40? ~ +85?
Features
- RRS
- Telemetry
- Option Board
- Intrinsically Safe Option
- Radio Check
- Alert Call
- Stun / Unstun
- Remote Monitor
- IP Site Connect
- Roaming
- Work Order
- 5 Tone Signalling
- 2 Tone Signalling
- HDC1200 Signalling
- DTMF (Phone Patch)
- Intelligent Audio
- VOX
- Priority Scan
- GPS SMS
- Vibration
- Scrambler (Analogue)
- Digital Encryption
- Multiple Key Encryption Decode
- Multilanguage Menu
- Power on & off user logo programming
- Voice Interrupt
- No of Contacts (Conventional)
- No of Contacts (Trunking)
- Text Messaging
- Quick Text Messages
- MPT1327 / 1343 Trunking
- Tier 3 Trunking
- Over-the-Air Programming
- Analogue Only Version
- Auto Power Select
Additional information
| Weight | 1 lbs |
|---|
Package includes
Package includes
- Antenna
- Li-Ion Battery
- Charger
- Belt Clip
- Power Adapter
